Call Out | Data |
---|---|
Wrench | WRENCH ERW-11 M |
Nut | NUT SXN-06M |
Preset Screw | SCW-ASC-SX06-SS |
B | 0.63 |
D1 | 0.5 |
L1 | 6.58 |
L2 | 5.52 |
L3 | 1.07 |
Drawing .stp | STEP |
